نصف مقطورة ثابتة الحرارة SCHMITZ Auflieger Tiefkühler Standard Double deck

Modelljahr: -1

Auflieger Tiefkühler Standard Double deck

Stahlfelge

Safety

• Rear underrun
• Antilock Braking System ABS
• Fire extinguisher holder 2x
• Telematics system

Comfort

• Roof ventilation with valve

Interior

• Double deck without beams

Exterior

• Air suspension
• Lift axle front
• Pallet box
• Toolbox 2x
• Spare wheel carrier double
• Ferry lashings
• Bolted chassis
• Gantry doors
• 1x15 and 2x7 pin plug
• Antispray

Cargo securing

• Cargo securing with certificate
• DIN EN 12642 (code XL) certificate
• Pharma certificate
• Load securing rail

Brake system

• Disc brake
• Schmitz ROTOS

Floor

• Aluminum floor

Wand

• Stirnwand verstärkt

Wall

• Frontwall recess for cooling
• Wall thickness45 mm

Cooling unit

• Carrier Vector 1950
• Diesel/Elektro
• 18.746 Operating hours Diesel
• 1.438 Operating hours electric

Loading area

• Length 13.410 mm, Width 2.490 mm, Height 2.650 mm
• Volume 88 m³

Tyre sizes

• 1. Achse: 385/65 R22.5 , Tread depth: 5 mm / 10 mm
• 2. Achse: 385/65 R22.5 , Tread depth: 12 mm / 9 mm
• 3. Achse: 385/65 R22.5 , Tread depth: 11 mm / 9 mm

Other dimensions and weights

• GVW: 36.000 kg
