آلة تصنيع المعادن Grob G350a - PW

Gewerbering 6, D-82140 Olching

Technical Datasheet: show contacts%20Datenblatt_89-001352.pdf

GROB G350a - PW

Control : Siemens Siemens 840 Dsl

Speed : 16000 rpm

Movement X/Y/Z : 600/770/805 mm

Tool holder : HSK 63

____________

Description

In General

Control system:Siemens 840 Dsl - GROB4Pilot

Traverse path X/Y/Z:600/770/805 mm

Speed:16,000 rpm

Tool holder:HSK 63

Spindle

Technology:Motorised spindle

Speed:16,000 rpm

Max. power:approx. 32 kW

Max. torque:approx. 206 Nm

Tool holder:HSK-63

NC swivel table

A-axis:-185°/+45°

C-axis:360°

Measuring systems:Direct

Clamping surface:400 x400 mm

Max. table load:approx. 300 kg

Workpiece clamping system:4x fluid connection

Tool magazin

Technology:magazine

Number of stations:50

Max. tool length:365 mm

Equipment

Measuring systems:Direct in all axes

Chip removal:Chip conveyor

Coolant supply:IKZ system

40 bar

Workpiece measurement:Infrared measuring probe

Tool breakage monitoring:Electromechanical

Automation:Pallet changer with set-up stations
