جرار maxus Maxus Wheeled tractor 130hp 4x4

Brand: MAXUS

Power: 130 HP

Chassis Model: TD

Drive Type: 4x4

Engine Model: 6-cylinder Diesel Engine

Tire Size: Chevron-pattern tires 14.9-28 / 20.8-38

Wheel Track: 1650 mm

Wheelbase: 2550 mm

Gear Shifting: 16F + 8R

Minimum Ground Clearance: 450 mm

Weight: 4500 kg

Cabin: Air Conditioning

Hydraulic Output Valve: 3 Groups

Tractor Type

Wheel Tractor

Frame Type / Roll Bar

Drive Type / 4WD

Application / General Use

Standard Counterweight (Front/Rear)

Front Counterweight: 40x11kg

Rear Counterweight: 60x8kg

Performance

Maximum Theoretical Design Speed (km/h): 31.67

Engine-to-Main Clutch Connection Mode: Direct Connection

Anti-Rollover Protection Device Type (Cabin or Roll Bar): AC Cabin Air Conditioning

Engine Construction

Type: Inline, Vertical, Water-cooled, Four-stroke

Intake Mode: Turbocharged with Intercooling

Number of Cylinders: 6

Engine Rated Speed (r/min): 2200

Cooling Mode: Water Cooling

Air Filter Type: Dry

Steering System

Type: Fully Hydraulic Steering System

Steering Control Mechanism: Steering System Control

Steering Mechanism Type: Front-wheel Steering

Transmission System

Gearbox Type: Mechanical System

Number of Transmission Gearboxes: 2

Main Transmission Position: In Gearbox 1

Main Gear Shifting Mode: Mechanical Step Transmission

Hydraulic Suspension System

Type: Independent Suspension

Suspension Type: Three-point Rear Suspension

Suspension Category: Category III

Full-opening Pressure of Working Device Safety Valve (Mpa): 19±0.5

Number of PTO Shaft Splines: 8
